Item
Unit
Specifications
Dimensions (L/W/H)
mm
Overall Dimensions: 4310 x 1552 x 1134 (Vehicle Height: 2200)
Wheelbase (Full Load)
Wheelbase (Full Load): 2408.5
Front Wheel Track
1352
Rear Wheel Track
Gross Vehicle Weight
kg
3000
Drive Type
/
Two Axles, Electric Motor Drive
Drivetrain Type
Rear-Wheel Drive
Maximum Axle Weight
Front Axle: 1000, Rear Axle: 2000
kw
Rated Power: 7.2
Motor Output Power
N.m
Rated Torque: 23, Peak Torque: 70
Motor Peak Torque
r/min
4500
Motor Maximum RPM (Revolutions Per Minute)
Lithium Ternary Battery
Battery Type
Kwh
Maximum Range (Expandable to 40)
Maximum Battery Capacity
Onboard Charging, Battery Swap
Charger
3.3
Charging Type
v
72
Voltage
Front Wheels: 500, Rear Wheels: 1000
Maximum Axle Load
6.50-16LT
Tires
Front and Rear Leaf Spring Non-Independent Suspension
Suspension
Front and Rear Drum Brakes, Hydraulic Braking, Linear Control
Vehicle Braking System
Electric Push Rod Linear Control + Electromagnetic Brake
Parking Brake
Linear Control
Accelerator Pedal
Riveted T-Beam Frame
Chassis Type
Electric Rear Axle Drive, Final Drive Ratio: 30
Drive Axle Type
Km/h
20
Maximum Speed (Typical Value)
2
Creep Speed
Non-Load-Bearing, Front-Mounted, Two-Person, Panoramic Front Windshield, Double Doors, Optional Air Conditioning
Cab Type
Front-Wheel Line-Control Steering
Steering
m
5.5
Minimum Turning Radius
°
30
Approach Angle
27
Departure Angle
39.5
Ramp Breakover Angle
165
Minimum Ground Clearance
Steering Angle
h
6~8
Maximum Range
s
5
0-20 km/h Acceleration Time
3
Driving Braking Distance
%
Driving Braking Gradient
Parking Brake Gradient
-40~60
Operating Environment Temperature
-20~50
