Item
Unit
Specifications
Dimensions (L/W/H)
mm
2360×1040×1680
Kerb weight of vehicle
kg
920
Front and rear overhang lengths
735/435
Approach angle/departure angle
°
16.5/21.5
Maximum gradient angle
%
12 (fully loaded)
Water tank volume
L
550
Gasoline engine type
/
Single cylinder, four-stroke, forced air cooling
Gasoline engine displacement
ml
389
Gasoline engine power
kw
10
Water pump flow rate
L/min
15.1
Front impact mechanism (with spot spray)
1
Washing width of impact spray
≥1050
Handheld spray gun (connected to water hose reel)
Water distribution
Manual ball valve contro
Warning lights
Water can be added from fire hydrants and manholes.
